7 Unbeatable Advantages of Our High-Performance Hydraulic Curving Machine
Hydraulic curving machines are the backbone of modern metal fabrication shops, offering unparalleled power and precision for shaping metal sheets. This specific model is engineered for efficiency, durability, and consistent performance, making it an indispensable asset for any serious manufacturer. Whether you’re working in automotive, aerospace, or construction, understanding the capabilities of this machine is key to optimizing your production line.
What is a Hydraulic Curving Machine?
A hydraulic curving machine, also commonly known as a plate roll or bending roller, uses hydraulic force to bend metal sheets into curves, cylinders, or other complex shapes. Unlike mechanical presses, the hydraulic system provides smooth, controllable power, which is essential for achieving precise curvatures without damaging the material. This process is critical for creating everything from pipes and tubes to structural components and architectural elements. The science behind this powerful forming process is explained in detail by resources like The Fabricators, a leading authority in metal forming.
In-Depth Look at Our Hydraulic Curving Machine’s Specifications
Our hydraulic curving machine is built with high-quality components to ensure reliability and long-term performance. Let’s break down the key technical parameters that define its capability.
Power and Drive System
-
Main Power: 0.85 KW – This powers the control systems and auxiliary functions, ensuring efficient energy use during operation.
-
Hydraulic Power: 5.5 KW – This is the core of the machine’s strength. The robust hydraulic pump generates the immense force required to bend even tough metals smoothly and consistently.
Performance and Operational Control
-
Roll Speed: 0-10 m/min – This variable speed control allows operators to fine-tune the process for different materials and thicknesses, ensuring optimal results whether you need speed or delicate precision.
-
Control System: PLC Panasonic – The use of a Programmable Logic Controller (PLC) automates operations, enhances repeatability, and minimizes the potential for human error. This brings a level of CNC-like precision to the curving process.
Material Compatibility and Bending Capacity
Understanding what a machine can handle is crucial for selecting the right equipment. This hydraulic curving machine is designed for a specific range of materials.
Sheet Specifications
-
Material Thickness: 0.3 – 0.9 mm – This range is ideal for light- to medium-gauge sheet metal, commonly used in ductwork, enclosures, and various fabricated products.
-
Width of the Sheet: 1000 mm – This defines the maximum width of the metal sheet that can be fed into the machine, determining the size of the cylinders or curves you can produce.
-
The Max Bending Angle: 120° – This parameter indicates the tightness of the curve the machine can achieve, providing significant flexibility for different design requirements.
Durability and Tooling
-
Punching Material: CR12, HRC 55-60, surface with chrome – The rollers are made from CR12 tool steel, heat-treated to a high hardness (HRC 55-60). The chrome plating reduces friction, prevents rust, and extends the life of the tooling, ensuring a smooth, mar-free finish on your products.
Why Choose Our Hydraulic Curving Machine?
Investing in this hydraulic curving machine means investing in the future of your fabrication capabilities. Its combination of a powerful hydraulic system, precise PLC control, and durable construction offers a significant return on investment through reduced labor time, minimal material waste, and high-quality, repeatable results. For businesses looking to understand the broader context of industrial machinery standards and safety, the Occupational Safety and Health Administration (OSHA) provides essential guidelines.
Your Partner for Broader Manufacturing Solutions
As your trusted machinery agent from China, we specialize in providing more than just a single solution. We understand that a complete production line requires multiple pieces of integrated equipment.
Do you require complementary machinery? We supply a wide range of industrial machines, including:
-
Cold Roll Forming Machines for continuous profile shaping.
-
Other Hydraulic Machines such as presses and shears.
-
Various Steel Materials to feed your production needs.
We are committed to providing comprehensive support and competitive pricing. If you are interested in this hydraulic curving machine or any other equipment, you are welcome to contact us for more detailed information, pricing, and technical consultation. Let us help you build a more efficient and profitable manufacturing operation.
